碳纖維+凱夫拉平紋
| 碳纖維與芳綸纖維混編布系列 Carbon Kevlar Hybrid Fabrics | ||||||||||
| 型號 Part No. | 纖維規格 Fiber Spec. | 纖維顏色 Fiber Color | 經緯密度 Fiber Count (10mm) | 編織方法 Weave | 質量 Weight (g/㎡) | 厚度Thickness ﹙mm﹚ | 幅寬Width ﹙mm﹚ | |||
| 經向 Warp | 緯向 Weft | 經向 Warp | 緯向 Weft | 經向 Warp | 緯向 Weft | |||||
| CKP031500195_Y1 | 3K | Kevlar1500 | 黑 Black | 黃Yellow | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKP031500195_Y2 | 3K+Kevlar1500 | 3K+Kevlar 1500 | 1黑+1黃Black+Yellow | 1黑+1黃Black+Yellow | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKT031500195_Y | 3K | Kevlar1500 | 黑 Black | 黃Yellow | 5 | 5 | 斜紋2/2 (Twill) | 195 | 0.2 | 100-1500 |
| CKP031500195_R1 | 3K | Kevlar1500 | 黑 Black | 紅Red | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKP031500195_R2 | 3K+Kevlar1500 | 3K+Kevlar 1500 | 1黑+1紅Black+Red | 1黑+1紅Black+Red | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKT031500195_R | 3K | Kevlar1500 | 黑 Black | 紅Red | 5 | 5 | 斜紋2/2 (Twill) | 195 | 0.2 | 100-1500 |
| CKP031500195_O1 | 3K | Kevlar1500 | 黑 Black | 橘黃Orange | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKP031500195_O2 | 3K+Kevlar1500 | 3K+Kevlar 1500 | 1黑+1橘黃Black+Orange | 1黑+1橘黃Black+Orange | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKT031500195_O | 3K | Kevlar1500 | 黑 Black | 橘黃Orange | 5 | 5 | 斜紋2/2 (Twill) | 195 | 0.2 | 100-1500 |
| CKP031500195-B1 | 3K | Kevlar1500 | 黑 Black | 藍Blue | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKP031500195-B2 | 3K+Kevlar1500 | 3K+Kevlar 1500 | 1黑+1藍Black_Blue | 1黑+2藍Black_Blue | 5 | 5 | 平紋(Plain) | 195 | 0.2 | 100-1500 |
| CKT031500195_B | 3K | Kevlar1500 | 黑 Black | 藍Blue | 5 | 5 | 斜紋2/2 (Twill) | 195 | 0.2 | 100-1500 |
| 碳纖維與玻璃纖維混編系列 CarbonFiberglass Hybrid Fabrics | ||||||||||
| 型號 Part No. | 纖維規格 Fiber Spec. | 纖維顏色 Fiber Color | 經緯密度 Fiber Count (10mm) | 編織方法Weave | 質量 Weight (g/㎡) | 厚度Thickness ﹙mm﹚ | 幅寬Width ﹙mm﹚ | |||
| 經向 Warp | 緯向 Weft | 經向 Warp | 緯向 Weft | 經向Warp | 緯向Weft | |||||
| CGP03300250 | 3K | 300Tex | 黑Black | 白White | 5 | 5 | 平紋(Plain) | 250 | 0.25 | 100-1500 |
| CGT03300250 | 3K | 300Tex | 黑Black | 白White | 5 | 5 | 斜紋2/2 (Twill) | 250 | 0.25 | 100-1500 |
| CGP06800480 | 6K | 800Tex | 黑Black | 白White | 4 | 4 | 平紋(Plain) | 480 | 0.48 | 100-1500 |
| CGT06800480 | 6K | 800Tex | 黑Black | 白White | 4 | 4 | 斜紋2/2 (Twill) | 480 | 0.48 | 100-1500 |
| 碳纖維與玄武巖纖維混編系列 Carbon Basalt Hybrid Fabrics | ||||||||||
| 型號 Part No. | 纖維規格 Fiber Spec. | 纖維顏色 Fiber Color | 經緯密度 Fiber Count (10mm) | 編織方法Weave | 質量 Weight (g/㎡) | 厚度Thickness ﹙mm﹚ | 幅寬Width ﹙mm﹚ | |||
| 經向 Warp | 緯向 | 經向 Warp | 緯向 Weft | 經向Warp | 緯向Weft | |||||
| CBP03330265 | 3K | 330Tex | 黑Black | 墨綠Dark-green | 5 | 5 | 平紋(Plain) | 265 | 0.25 | 100-1500 |
| CBT03300265 | 3K | 300Tex | 黑Black | 墨綠Dark-green | 5 | 5 | 斜紋2/2 (Twill) | 265 | 0.25 | 100-1500 |
| CBP06800480 | 6K | 800Tex | 黑Black | 墨綠Dark-green | 4 | 4 | 平紋(Plain) | 480 | 0.45 | 100-1500 |
| CBT06800480 | 6K | 800Tex | 黑Black | 墨綠Dark-green | 4 | 4 | 斜紋2/2 (Twill) | 480 | 0.45 | 100-1500 |
